SORAA VIVID MR16 E11 (JAPAN)
SORAA’s E11 MR16 is the first ever narrow spot option in this form factor, outperforming halogen lamps. Neither halogen nor other LED competitors can create point sources small enough to achieve these narrow beam angles and high center beam intensity. Now, powered by SORAA’s B + V technology, our E11’s still feature all of SORAA’s signature elements of light quality, with an even wider range of power options. Choose the right product series for your needs.
VIVID SERIES: Our full-spectrum series brings you both VIVID COLOR (CRI-95, R9-95) and NATURAL WHITE Technology, with market-leading CBCP.
Color
Black
RAL custom finishes available
SORAA VIVID MR16 E11 (JAPAN) Specifications
- Narrow spot CBCPs of 6000Cd at 95CRI
- Dimmable
- Suitable for damp locations. Enclosed fixture compatibility allows 7.5W to be operated in outdoor locations
- 100V, at 7.5W
- Standard E11 form factor, PSE compliant
- Available in 2700K, 3000K, 4000K, in beam angles of 10°, 25°, and 36°
Product Matrix
2700K
|
Model #
|
Code
|
Watts
|
Beam
|
Lumens
|
Peak Intensity
|
Snap Compatible
|
|---|---|---|---|---|---|---|
|
SM16J-07-10D-927-03-S5
|
02097
|
7.5
|
10
|
390
|
5710
|
|
|
SM16J-07-25D-927-03-S5
|
02109
|
7.5
|
25
|
410
|
2260
|
|
|
SM16J-07-36D-927-03-S5
|
02121
|
7.5
|
36
|
410
|
1070
|
|
3000K
|
Model #
|
Code
|
Watts
|
Beam
|
Lumens
|
Peak Intensity
|
Snap Compatible
|
|---|---|---|---|---|---|---|
|
SM16J-07-10D-930-03-S5
|
02101
|
7.5
|
10
|
410
|
6000
|
|
|
SM16J-07-25D-930-03-S5
|
02113
|
7.5
|
25
|
435
|
2400
|
|
|
SM16J-07-36D-930-03-S5
|
02125
|
7.5
|
36
|
435
|
1130
|
|
4000K
|
Model #
|
Code
|
Watts
|
Beam
|
Lumens
|
Peak Intensity
|
Snap Compatible
|
|---|---|---|---|---|---|---|
|
SM16J-07-10D-940-03-S5
|
13337
|
7.5
|
10
|
430
|
6290
|
|
|
SM16J-07-25D-940-03-S5
|
13340
|
7.5
|
25
|
455
|
2510
|
|
|
SM16J-07-36D-940-03-S5
|
13338
|
7.5
|
36
|
455
|
1190
|
|
